True-to-Life Macro Shots
Taking advantage of the life-size magnification capability and deep depth of field, this compact lens offers excellent performance in shooting from casual macro shots, like flowers or food, to impressive portraits. It features an outstanding closest focusing distance of 0.105m allowing you to shoot true-to-life macro shots of flowers or small accessories.
240 fps Drive Capability
The inclusion of a stepping motor makes the focusing action smooth and silent for use in both photo and video recording. When mounted on the LUMIX G cameras, you can take advantage of the high-speed, high-precision Contrast AF system with a 240 fps digital signal exchange, achieving high speed AF faster than approx. 0.5 sec (infinity - 0.105m).
Compact & Reliable Metal Design
Comprising of 9 lenses in 9 groups including an aspherical lens, the lens system achieves both high compactness and high optical performance. It incorporates a superior inner focus system that enables excellent resolution and contrast from full life-size magnification to infinity. Offered in sharp, metallic black, this lens stylishly matches the LUMIX G cameras.
MEGA O.I.S. (Optical Image Stabilizer)
Optical Image Stabilizer in the lens effectively compensates for the handshake.
Specifications
True-to-Life Macro Shots
Taking advantage of the life-size magnification capability and deep depth of field, this compact lens offers excellent performance in shooting from casual macro shots, like flowers or food, to impressive portraits. It features an outstanding closest focusing distance of 0.105m allowing you to shoot true-to-life macro shots of flowers or small accessories.
240 fps Drive Capability
The inclusion of a stepping motor makes the focusing action smooth and silent for use in both photo and video recording. When mounted on the LUMIX G cameras, you can take advantage of the high-speed, high-precision Contrast AF system with a 240 fps digital signal exchange, achieving high speed AF faster than approx. 0.5 sec (infinity - 0.105m).
Compact & Reliable Metal Design
Comprising of 9 lenses in 9 groups including an aspherical lens, the lens system achieves both high compactness and high optical performance. It incorporates a superior inner focus system that enables excellent resolution and contrast from full life-size magnification to infinity. Offered in sharp, metallic black, this lens stylishly matches the LUMIX G cameras.
MEGA O.I.S. (Optical Image Stabilizer)
Optical Image Stabilizer in the lens effectively compensates for the handshake.
Specifications
- Lens Construction
- 9 elements in 9 groups (1 aspherical lens)
- Mount
- Micro Four Thirds mount
- Optical Image Stabilizer
- Yes (MEGA O.I.S.)
- Focal Length
- f=30mm (35mm camera equivalent 60mm)
- Aperture Type
- 7 diaphragm blades / Circular aperture diaphragm
- Maximum Aperture
- F2.8
- Minimum Aperture
- F22
- Closest Focusing Distance
- 0.105m / 0.345'
- Maximum magnification
- Approx. 1.0x / 2.0x (35mm camera equivalent)
- Diagonal Angle of View
- 40deg.
- Filter Size
- Diameter: 46mm / 1.8in
- Max. Diameter
- Diameter: 58.8mm / 2.3in
- Overall Length
- Approx. 63.5mm / 2.50" (from the tip of the lens to the base side of the lens mount)
- Weight
- Approx. 180g / 6.35oz (excluding lens cap and lens rear cap)
